Product

Keyword: Alloy Pipe

Product Name:Inconel 600 Pipe

Inconel 600 Pipe Description
Inconel 600 alloy is mainly composed of nickel and chromium, with a nickel content of approximately 72% and a chromium content of approximately 14%-17%. In addition, the alloy contains a smaller proportion of iron, as well as trace amounts of silicon, carbon and manganese. This unique chemical composition gives Inconel 600 pipe excellent corrosion resistance and mechanical strength at high temperatures. Inconel 600 alloy has excellent mechanical properties over a wide temperature range and is capable of use at temperatures up to 1093°C (2000°F) without losing good creep and fracture resistance. Its corrosion resistance is particularly remarkable and it is highly resistant to a variety of corrosive media, including seawater, organic acids, and high-temperature and high-pressure steam environments.

Product Parameters
Product Name Inconel 600 Pipe
Outer Diameter Round Pipe: 4mm-200mm
Square Pipe: 10*10mm-100*100mm
Rectangular Pipe: 10*20mm-50*100mm
Wall Thickness 0.6mm-6.0mm
Length 1-6 meters, Length can be customized
Standard ASTM, AISI, JIS, GB, DIN, EN, etc.
Surface Black, Bright Polished, Rough Turning, Matt Surface Treatment, No.4, BA, etc.
Certificate ISO, SGS, BV
Production Technology Hot Rolling, Cold Rolling
Chemical Composition
C Si S Cr Mn Fe Ni Cu
0.15 max 0.5 max 0.015 max 14.0 - 17.0 1.0 max 6.0 - 10.0 72.0 min 0.5 max
Mechanical Properties
Tensile Strength (ksi) 0.2% Yield Strength (ksi) Elongation% in 2 inches
110 85 10
Physical Performance
Property Units Temperature in°C
Density 8.47 g/cm³ Room
Specific Heat 0.106 Kcal/kg.C 22°
Melting Range 1354-1413°C -
Modulus of Elasticity 214 KN/mm² 22°
Electrical Resistivity 103 µΩ.cm Room
Coefficient of Expansion 13.3 µm/m °C 20 - 100°
Thermal Conductivity 14.9 w/m-° K 20°
