Hastelloy X Pipe Description
Hastelloy X pipes have excellent corrosion resistance and can be used for a long time in various corrosive environments. This is because a large number of alloying elements are added to the alloy, such as nickel, chromium, molybdenum, etc. These elements form a dense oxide film on the surface of the alloy, which can effectively resist the erosion of various chemical substances. Hastelloy X pipe has excellent high-temperature strength and can maintain high strength and hardness in high-temperature environments. This is because the alloying elements in the alloy can form strengthening molybdenum, which improves the tensile strength and yield strength of the alloy. Lastly, Hastelloy X has good processing properties and can be used for casting, forging, rolling and other processing processes. During the processing process, the fluidity and plasticity of the alloy are relatively good.
| Product Parameters | |
| Product Name | Hastelloy X Pipe |
| Outer Diameter |
Round Pipe: 4mm-200mm Square Pipe: 10*10mm-100*100mm Rectangular Pipe: 10*20mm-50*100mm |
| Wall Thickness | 0.6mm-6.0mm |
| Length | 1-6 meters, Length can be customized |
| Standard | ASTM, AISI, JIS, GB, DIN, EN, etc. |
| Surface | Black, Bright Polished, Rough Turning, Matt Surface Treatment, No.4, BA, etc. |
| Certificate | ISO, SGS, BV |
| Production Technology | Hot Rolling, Cold Rolling |
| Chemical Composition | |
| C | Si | P | S | Cr | Mn | Fe | Co | Ni | Mo | W |
|---|---|---|---|---|---|---|---|---|---|---|
| 0.05 - 0.15 | 1.0 max | 0.04 | 0.03 | 20.5 - 23.0 | 1.0 max | 17.0 - 20.0 | 0.5 - 2.5 | Remainder | 8.0 - 10.0 | 0.2 - 1.0 |
| Mechanical Properties | ||
| Tensile Strength (ksi) | 0.2% Yield Strength (ksi) | Elongation% in 2 inches |
|---|---|---|
| 95 | 35 | 35 |
| Physical Performance | ||
| Property | Units | Temperature in°C |
|---|---|---|
| Density | 8.22 g/cm³ | 22°C |
| Specific Heat | 0.116 Kcal/kg. | Room |
| Melting Range | 1260-1355°C | - |
| Modulus of Elasticity | 205 KN/mm² | Room |
| Electrical Resistivity | 118.3 µΩ.cm | 22° |
| Coefficient of Expansion | 13.9 µm/m °C | 26 - 93° |
| Thermal Conductivity | 9.1 w/m-° K | 21° |
